POWER INPUT

Single phase for one vehicle – any 2w or 4w

Power Connection: P + N + PE

Input Voltage: 230 VAC±10%

Frequency: 50Hz±10%

USER INTERFACE

Display: On-board software, Prepayment

User Authorization: KIOSK Software

COMMUNICATION

Network Connectivity: GSM Modem (4G LTE fallback to 2G) and Wi-Fi

Communication Protocol: OCPP v1.6j - Internal (Inbuild CT) Metering supported

ENVIRONMENT

Operating Temperature: -20ºC to 70ºC

Storage Temperature: -40ºC to 70ºC

Humidity: 5% to 95% without condensation

Place of Installation: Indoor and Outdoor

MECHANICAL DESIGN

Cooling: Natural Cooling

Installation: Wall / Pole Mounted

PROTECTION

Push Button Electrical: Emergency Stop Button

Protection: Over Current, Over/Under Voltage, Surge Protection, Short Circuit Protection, Earth-Leakage, Ground Fault

POWER OUTPUT

Rated Power: 3.3KW

Rated Output Current: 16 Amp

No. of Output: 1

Plug: IEC60309 industrial socket
